Tapping Collets (GT Series)

TENSION & COMPRESSION FLEXIBILITY

Float compensation for perfect threads

High-precision GT series tapping collets designed for quick-change tapping chuck adapters. These collets provide the essential float mechanism that allows axial movement during tapping, compensating for any pitch mismatch between spindle feed and tap cutting action.

GT MODEL SELECTION GUIDE

GT Model	Tap Size Range	Applications
GT12	M1.5 - M10	Small threads, precision work
GT24	M12 - M22	Medium threads, general purpose
GT42	M24 - M33	Large threads, heavy duty

KEY BENEFITS

Square drive prevents spinning

ISO & JIS standards supported

Quick-change collet system

Extended tap life from float action

Compatibility: These collets work with all GT-series quick-change tapping chucks including BT, straight shank, side lock, and Morse taper adapters.

Compatible Tapping Accessories

BT Quick Change tapping Chuck adapter

5 variants

Straight quick change tapping chuck adapter

5 variants

Specifications

Material & Construction

High-precision tapping collets with ISO and JIS compatibility

Tapping Collets

Name: Tapping Collets
Brand: ZHUZHOU SENO
SKU: tapping-collets
Availability: InStock
