HSS Tap Metric, Cobalt5% - Coated
High Speed Steel HSS-M35 Cobalt 5% Metric Tap - TiN Coated
• Material: HSS-M35 (5% Cobalt)
• Coating: TiN (Titanium Nitride) Gold Coating
• Thread Type: Metric (ISO)
• Application: Threading in stainless steel, hardened steel, and difficult-to-machine materials
• Available Types: Straight Flute and Spiral Flute
• Features: Right-hand cut, standard pitch
• Superior heat resistance and hardness retention
Straight Flute: Best for through holes and general purpose
Spiral Flute: Best for blind holes, improved chip evacuation
Available sizes from M3 to M52.
Select Specifications
φ(d)=Cutting Diameter | R=Radius | D=Shank Diameter | I=Cutting Length | L=Overall Length | All in mm
D=Diameter | L1, L2, L3=Length Dimensions | L=Overall Length | D1=Shank Diameter | All in mm
Select blade width, groove depth (T), and working radius range to find the right Face Groove tool
Select boring diameter range, shank diameter (D), and insert type (C=diamond/T=triangular) to find the right boring head
Select CBA model (complete boring range) and internal boring range to find the right micro finish boring head
Select LBK model (matches your CBA boring head) and extension length to find the right extension rod
Select BT type (spindle taper), LBK number (locking block socket), CBA head model, and projection length (L1) to find the right boring head shank
HRC≤56 is recommended for best price/performance ratio with newest nano-black coating technology.
